Product name : 5150-5850MHz Sector Antenna 65 Degrees 18dBi
Product No. : DT-SPA5150-5850-18-60
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:



ELECTRICAL
Model DT-SPA5150-5850-18-60
Frequency Range 5150-5850MHz
Gain 18dBi
Beamwidth H: 60° , E:
VSWR ≤1.5
F/B Ratio ≥30dB
Polarization Vertical
Max Power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or customized
Antenna Dimension          460*150*40mm
Weight 3.5kg
Radome Material UPVC
Diameter of the Pole Φ50-105mm
Rated Wind Velocity 60m/s
Connector Position                                Bottom
